Motor
1. Copper wire motor
2. Maximum ambient temperature: 40°C
3. Protection class: IPX4
4. Insulation class: F
5. Voltage options:
Single phase: 220V–240V 50Hz or 60Hz, 110V–127V 50Hz or 60Hz
Three phase: 220V 50Hz or 60Hz, 380V 50Hz or 60Hz
1. Copper wire motor
2. Maximum ambient temperature: 40°C
3. Protection class: IPX4
4. Insulation class: F
5. Voltage options:
Single phase: 220V–240V 50Hz or 60Hz, 110V–127V 50Hz or 60Hz
Three phase: 220V 50Hz or 60Hz, 380V 50Hz or 60Hz
Application range
Suitable for the delivery of clean water or other liquids similar to clean water. Ideal for household water supply, garden watering, and other domestic uses.
Suitable for the delivery of clean water or other liquids similar to clean water. Ideal for household water supply, garden watering, and other domestic uses.
Model description
Technical parameters
| Model | Power | Max.Flow (L/MIN) |
Max.Head (M) |
MAX.Suct (M) |
In/out Pipe diameter |
|
|---|---|---|---|---|---|---|
| KW | HP | |||||
| SJm370H | 0.37 | 0.5 | 30 | 50 | 25 | 1.25″×1″ |
| SJm550H | 0.55 | 0.75 | 30 | 60 | 25 | 1.25″×1″ |
| SJm750H | 0.75 | 1 | 35 | 82 | 30 | 1.25″×1″ |
| SJm1100H | 1.1 | 1.5 | 35 | 106 | 33 | 1.25″×1″ |
| SJm1500H | 1.5 | 2 | 35 | 120 | 33 | 1.25″×1″ |
